How to Choose your Wire Manufacturers?

ISO Certificated Polyimide Round Enamel Coated Magnet Wire has better performance than all other types of enameled wires. Polyimide paint film has only abrasion resistance slightly worse than polyester and polyvinyl acetal enameled wires. In order to improve this performance, most of the current Use polyester imide and polyamide imide to prepare enameled wire, which can increase the solid content of the paint, but the heat resistance is somewhat reduced.

UL Certificated 220 High Thermal Class Oxidized Film Aluminum Wire and aluminum strip insulated with aluminum oxide film are used in the fields of electronics, missiles, nuclear reactors, aerospace and aircraft industries. The oxide film has high flexibility and is suitable for winding electromagnetic coils of various shapes and sizes. The use of round or rectangular aluminum wires and aluminum strips can save 50% of metal, so it has commercial value. For example, linear motors and medical equipment industries are widely used because of their light weight and low inertia. For rotating equipment, light weight can simplify the dynamic balance, thus reducing the vibration generated by the dynamic balance, thereby improving the sensitivity of the moving coil and its high-frequency response.

Copper-clad aluminum wire refers to a wire with aluminum core wire as the main body and a certain proportion of copper layer plated on the outside. It can be used as a conductor for coaxial cables and wire and cable conductors in electrical equipment. The aluminum wire has a small specific gravity, but its welding performance is not good. Therefore, the copper-clad aluminum wire is wrapped with a copper layer on the aluminum wire. This copper-clad aluminum wire can not only take advantage of the small aluminum specific gravity, but also improve the welding performance.

Electrical wiring to be run in conduit comes in individual strands, encased in insulation to protect the wire and insulate it from other wires and the conduit. Wires come in ither solid or stranded, depending on the wire size. Bare conductors are available for ground wires only. The insulation is made to take on some rather extreme conditions. Heat-, oil-, gasoline- and water-resistant coatings are all available to help your Insulated electric wire survive.

British Standard Wire Gauge (often abbreviated to Standard Wire Gauge or SWG) is a unit for denoting wire size given by BS 3737:1964 (now withdrawn). It is also known as the Imperial Wire Gauge or British Standard Gauge. Use of SWG sizes has fallen greatly in popularity, but they are still used as a measure of thickness in guitar strings and some electrical wire. Cross sectional area in square millimetres is now the more usual size measurement for wires used in electrical installation cables. The current British Standard for metallic materials such as wire and sheet is BS 6722:1986, which is a solely metric standard.

FiberGlass covered Aluminum wire is according to customers requirement, aluminum conductor is evenly covered with one or two layers of non-alkali fiberglass, then it¡¯s impregnated in compatible insulating coating of required thermal class baked to make a whole between fiberglass and Aluminum conductor (optionally be applied to polyester and polyamide).

Resistance:
Take 1m of the enameled wire to be inspected, scrape off the paint film at both ends, measure the resistance of the enameled wire, the resistance measurement value should be within the resistance range of GB/T6109; the standard temperature is 20 degrees, the conversion formula: 20 degrees resistance/234.5+standard Temperature = actual measured resistance/234.5 + measured temperature;

Fiberglass Covered Aluminum Wire Production Proce

One step :
Take the pure aluminum material drawing into the aluminium rod wire;

Two step :
Through the extrusion production line, take the aluminum rod wire into extruding and coarse drawing operation, then becoming the requirement specification of Bare aluminium wire;

Three step :
Take up the Bare aluminum wire conductor, and inspection the bare wire coil products;

Four step :
Annealing the bare aluminum wire, and placed neatly, ready to production;

Five step :
Pay-off the wire coil products, ready to fiber glass covering production;

Six step :
Taking into straightening and tension levelling operation, and then for the covering fiber glass;

Seven step :
Doing the fiber-glass covering operation, and inspecion the production process;

Eight step :
Packing the fiberglass covered wire products, and placed neatly in the warehouse.

Polyimide Film Covered Aluminum Wire Production Process

One step :
Take the pure aluminum material drawing into the aluminium rod wire;
Two step :
Through the extrusion production line, take the aluminum rod wire into extruding and coarse drawing operation, then becoming the requirement specification of Bare aluminium wire;

Three step :
Take up the Bare aluminum wire conductor, and inspection the bare wire coil products;

Four step :
After annealing the alumium wire coil , cleaning and pay-off the wire coil, ready to next operation;

Five step :
Taking into straightening and Tension levelling operation, varnish treat the surface of wire, and then for the glass fiber covered;

Six step :
And then for baking the fiberglass wire , pulling the finished wire, and take-up the fiberglass wire products.

Copper paint package wire production process principle

Copper lacquer wires are coated with respective lacquer solutions, and then cured by solvent volatilization and paint film.The earliest enamel wire is oily painted wire, made from tung oil.Its paint film is abrasion resistant, and cannot be used directly to make motor coils and windings, and the cotton yarn can be added to the layer.Later, polyethylene glycol formaldehyde lacquer wire came out, and its mechanical properties were greatly improved, which can be used directly for motor windings, which is called high-strength enameled wire.

Enameled wire is a main type of winding wire. It is made of a metal conductor as a conductive inner core and coated with a polymer insulating layer. It is mainly composed of these two parts; it is the conversion of electromagnetic energy into mechanical energy, heat energy, sound energy, light energy or machinery Functional materials that convert energies such as heat, heat, chemistry, sound and light into electromagnetic energy.

An electrical motor is one kind of machine which is used to change the energy from electrical to mechanical. Most of the motors work on the principle of interaction among the electric current as well as the magnetic field within a wire winding. This can generate force in the form of shaft rotation. These motors can be powered with DC or AC sources. The DC sources are batteries whereas the AC sources are inverters, power grids, generators. A generator is mechanically similar to the motor but works in the reverse direction by converting the energy from mechanical to electrical. An electric motor can be built with the rotor, stator, air gap, windings, bearings, & commutator. The classification of motors can be done with considerations like the type of power source, construction, motion output type, and applications. This article discusses what is a motor winding, types, and its calculation.

1. Cutting
The enameled wire is composed of a conductor and an insulator, and the hardness of the two parts is very soft, so it can be cut by using a TabCUT-200 precision cutting machine with a general SiC cutting chip. Since the insulator is coated on the conductor, and its hardness and ductility are quite different, and the insulating layer has a certain degree of peeling, it is better to use some soft materials such as tin foil, rubber, etc. to wrap the cutting part when cutting. Up to prevent the insulation layer at the fracture from peeling off after cutting.

Round Enameled Wire is used for transformer coil winding and motor winding, also called electric motor winding wire. And to Measure The Specifications Of Round Enameled Wire is important, include the conductor diameter and insulation diameter.

The samples for the dielectric strength test are also twisted pairs, and the number is 5 pairs. During the test, the voltage was applied at a boosting rate of 500V/S until breakdown, and the voltage at the time of breakdown was recorded. The requirements for dielectric strength in the NEMA MW1000 standard will vary according to different wire diameters, different paint film thicknesses, and different enameled wire types.

The voltage resistance performance of enameled wire is mainly affected by several factors:
1. The thickness of the insulating layer, not much nonsense;
2. The degree of aging of the insulating layer and the degree of baking affect the withstand voltage.
3. The quality of the insulation layer is mainly the pinhole performance.

Glass-fiber covered aluminum magnet wire used to have weak coating strength (abrasion resistance, shock resistance, and flexibility). However, that disadvantage has been significantly improved recently by refining material selection and manufacturing methods. The demand for glass-fiber covered aluminum magnet wire is increasing as the wires have excellent uniformity and electrical properties under high temperatures and humidity.

Main Applications:
All kinds of household electric motors, vacuum cleaner motor, electric motor
All kinds of transformers, inductors, rectifiers
All kinds of fan motor
All kinds of high frequency electric appliance

Enameled wire coating is mainly used for coating and insulation of enameled wire cores. Since the wire will be subjected to heat, chemical and various mechanical forces in the process of winding coils and embedding wires, the enameled wire paint is required to have good coating properties (that is, uniform coating), and strong paint film adhesion.

Fiberglass Covered Insulated rectangular aluminum wire is in accordance with customer requirements in aluminum conductor uniform whole winding package 1-2 layers of alkali-free fiberglass, with the necessary temperature resistance index and compatible adhesive paint dipping and baking process, glass fiber and conductor between bonded into a whole.

Features of Aluminum Enameled Electric Wire 1.5mm For Moxico
1) Excellent bending performance
2) High flexibility of enamel
3) Good wear resistance
4) High mechanical properties
5) Higher thermal performance
6) Good resistance to refrigerants and Freon
7) Suitable for windings subjected to continuous high temperature and mechanical stress
8) Good chemical resistance
9) Excellent mechanical and chemical properties

After the product is manufactured, whether its appearance, size and performance meet the requirements of the technical standards of the product and the technical agreement of the user must be judged by the inspection beam and measured; the test shall be compared with the technical standard of the product or the technical agreement of the user and meet the requirements If it is qualified, otherwise, it is unqualified. Passing the inspection can reflect the stability of the enameled wire product quality, the material and the rationality of the process. Therefore, the quality inspection has the function of checking, preventing and identifying.

Thermal Class 105 / 133 / 155 Grade Enameled Wire includes
Polyethylene formaldehyde enameled copper wire (PVF)
Polyester enameled copper wire (PEW)
Polyurethane enameled copper wire (UEW).
Application: Normally used for Oil-filled transformers, motors, micro motors, transformers and high frequency coils, relays, magnetized coils

Principle: Water molecule (HHO) decomposes water into oxygen and hydrogen through electrolysis. Hydrogen is combustible. Oxygen supports combustion. These two gases are ignited to form a hydrogen-oxygen flame. In layman’s terms, “water turns into fire”

3.1 Elongation:
The standard refers to GB/T6109, inspection method: stretch the instrument
Calculation method: ratio of (length after stretching-length before stretching)/length before stretching;

3.2 Snap off:
The standard is to pull at a speed of 2 meters per second to check that the paint film is not cracked,

3.3 Round rod winding:
Wrap the enameled wires of different specifications and the corresponding copper rods around ten times to check that the paint film is not cracked. The diameter of the copper rods refers to the requirements of GB/T6109;

3.4 Thermal shock: Put the winding enameled wire in an oven (hanging in the middle of the oven) for 0.5 hours. The temperature of the oven corresponds to the specification requirements of the enameled wire. Refer to GB/T6109. After the drying, check that the paint film is not cracked.

Axalta today announced that it has reached a final agreement to acquire Anhui Shengran Insulation Materials Co., Ltd. (“Anhui Shengran”). Anhui Shengran is a leading manufacturer of high-quality enameled wire paint in China. Its products are widely used in consumer electronics, electric vehicles and industrial fields. Subject to the conditions of the agreement, the transaction is expected to be completed in the second quarter of 2021. Financial terms have not been disclosed.

In the long-term thermal aging test, three or more temperature points are usually selected for accelerated aging, commonly known as “three-point aging”.

The samples for the aging test are stranded enameled wire pairs. The production of the stranded pairs should meet the requirements of ASTM D2307 or NEMA 1000 standards, including the weight to be applied when making the stranded pairs, the number of twisted turns, the effective length of the stranded area, and The length of the two ends of the twisted pair, etc. When making a twisted pair, the required force and the number of twist turns will vary depending on the diameter of the wire. The effective length of the stranded area has nothing to do with the wire diameter, the effective length is 121¡À6 mm, and the two ends are at least 50 mm long. At least 10 twisted pairs per temperature point and mounted on twisted pair racks for high temperature aging test.

¡ñ Conductor resistance. Measure with a conductor resistance tester, and then change to the value at 20¡ãC for comparison.
¡ñInsulation destruction voltage. Twist two enameled wires, apply voltage between the conductors, and judge by the damage voltage of the paint film. This performance is analyzed and judged through two tests of normal state and cold state breakdown voltage.
¡ñPaint film continuity (pinhole). Check the small holes of the paint film with a certain length of the test material. The project is tested by a high-pressure paint film continuity tester.

How to Choose your Wire Manufacturers? You want to choose competitive wire manufactuer, should think about the
Factory certificate
Wire specifications
Copper or aluminum pure

Insulation, also called insulating coatings, is a kind of coating with excellent electrical insulation. It has good electrochemical properties, thermal properties, mechanical properties and chemical properties, mostly varnishes, but also colored paints. Insulating paint is a special paint in the paint category. Insulating varnish is an important insulating material based on high molecular polymers that can be cured into an insulating film or insulation under certain conditions. Insulating paint is composed of base material, flame retardant, curing agent, pigment and filler, and solvent. It introduces its composition, usage classification, grade classification, requirements, development trend, etc. in detail.
