6mm enameled copper clad aluminum wire magnet copper clad speaker coil

Product Introduction :
Nomex covering corresponds to class H insulation is mainly used in the construction of condensers and capacitors. Main application of it is in shielding of cables in high temp. environments (200¡ãC) such as dry type transformers, military and aerospace cables. Nomex covered conductors are more effective in condition where temperature resistance and dielectric strength requirements are high.

By extrusion of bare aluminum wire wrapped and Nomex Paper covered wire, the mechanical performance and electrical performance better, instead of making difficult composite enameled flat wire, suitable for transformer, winding of lifting electromagnet, electric welding machine and other products.

Enameled wire is the most widely used electromagnetic wire in the production of low-voltage products. A key performance requirement of this electromagnetic wire is the continuity of the paint film, which is to check the number of pinholes in the paint film under a certain length. When checking the number of pinholes, use a professional paint film continuity tester. The fewer the number of pinholes, the better the paint film integrity of the magnet wire.

7 type of enameled wire in accordance with insulation materials, list the thermal class, advatanges and application per type of enameled wire. Enameled wire types also can be divided into copper magnet wire and aluminum wire in accordance with conductor.

Main Applications:
All kinds of household electric motors, vacuum cleaner motor, electric motor
All kinds of transformers, inductors, rectifiers
All kinds of fan motor
All kinds of high frequency electric appliance

Enameled wires are widely used in industrial production, household appliances and other industries. The main properties and uses of various enameled wires are as follows: Various machines, communication equipment, meters, relays, small transformers, etc.

The electrical insulation system for wires used in generators, electric motors, transformers, and other wire-wound electrical components is divided into different classes by temperature and temperature rise. The electrical insulation system is sometimes referred to as insulation class or thermal classification. The different classes are defined by NEMA, Underwriters Laboratories (UL), and IEC standards.

The enamel wire is a wire having an insulating layer, which is a transformation of electromagnetic energy in a winding form, also known as a winding wire.

The multi-shaped enamel wire refers to a metal wire for winding electromagnetic coils with an insulating paint, also known as electromagnetic wires. The multi-shaped enameled wire is the primary raw material of electrical, motor and household appliances, telecommunications, electronic external electromagnetic windings. In the future, follow the rapid development of industrial appliances, household appliances, telecommunications, electronic products, etc. Market and application fields.

The samples for the dielectric strength test are also twisted pairs, and the number is 5 pairs. During the test, the voltage was applied at a boosting rate of 500V/S until breakdown, and the voltage at the time of breakdown was recorded. The requirements for dielectric strength in the NEMA MW1000 standard will vary according to different wire diameters, different paint film thicknesses, and different enameled wire types.

Submersible Winding Wire normally chooses the enameled copper wire with good performance
Longer life
Best Tensile Strength
Easy to Wind
Savings up to 25%

Enameled wire motors, electrical appliances, home appliances, communications, electronic information, instrumentation, power tools, automobiles and other industries provide supporting basic material industries. They are the main and key raw materials for electromagnetic windings of motors and electronic instruments. The rapid development of electronic products, etc., has brought a broader application field and market to enameled wires, but at the same time, higher requirements have been put forward for enameled wires, and enameled wires have continued to develop towards a high level and high quality.

ISO Certificated Polyimide Round Enamel Coated Magnet Wire has better performance than all other types of enameled wires. Polyimide paint film has only abrasion resistance slightly worse than polyester and polyvinyl acetal enameled wires. In order to improve this performance, most of the current Use polyester imide and polyamide imide to prepare enameled wire, which can increase the solid content of the paint, but the heat resistance is somewhat reduced.

Transformer insulation wire is usually circular. Silk covered wire, also known as cotton covered wire, it is a thread or yarn on copper coated insulation materials, such as to increase the mechanical strength and dielectric strength of the wire.

Silver plated copper wire is manufacture with the combination of silver and copper and Silver Plated Copper Electrical Wire is manufactured using grade copper and silver; the industrial standards are always kept into the consideration.

Kapton insulated aluminium wires are suitable for both HV and UHV applications at temperatures ranging from -269 to 200¡ãC with maximum bakeout temperature of 260¡ãC.
Kapton insulated aluminum wire is designed for use in high & ultra-high vacuum applications. Kapton has high mechanical strength, excellent electrical insulation properties, and low outgassing rates making it ideal for use as an in-vacuum insulator. These wires can be utilized in temperature ranges from 4K to 260¡ãC.

Enameled wire is a main type of winding wire. It is composed of a conductor and an insulating layer. After the bare wire is softened by annealing, it is painted and baked many times.

General purpose enameled wire (ordinary wire): Mainly used for winding wires in general motors, electrical appliances, instruments, transformers, etc., such as polyester enameled wire and modified polyester enameled wire.

The lacquered wire is composed of two of the conductor and the insulating layer. After the bare wire is deck, after multiple painting, baking.The enameled wire can be used in transformers, motors, motors, electrical, ballasts, inductance coils, disadvantages, audio coils, microwave coils, electric fans, instrumentation, and the like.

Compared with general round wires, flat enameled wires have the following advantages:
Higher floor area ratio and better use of space: The high conductor density enables coils and components of the same size to achieve higher efficiency, save materials and reduce costs.

The structure of enameled wire is very simple, consisting of conductor and insulating layer. Because of its high dielectric strength, small footprint and good heat dissipation, it is widely used as a coil winding in motors and transformers.

Magnet Wire: enameled wire, winding wire, enamelled wire, magnetic wire, conductor covered
Type: copper winding wire, aluminum enameled wire
Application: motors, generators, transformers, and electric vehicles
Thermal Class: 130, 155, 180, 200, 220, 240

Magnet wire or enameled wire is a copper or aluminium wire coated with a very thin layer of insulation. It is used in the construction of transformers, inductors, motors, generators, speakers, hard disk head actuators, electromagnets, electric guitar pickups and other applications that require tight coils of insulated wire.

The infrared spectrum analysis test is based on the standard UL746A, which only confirms the chemical composition of the paint film, establishes the infrared spectrum and retains it. After the enameled wire is certified, samples will be sampled for testing every year during the follow-up inspection service. The infrared spectrum made by the paint film on the sampled sample needs to be compared with the infrared spectrum established on the sample at the time of certification. The two infrared spectrums must be comparable. superior.

Paper Wrapped Aluminum wire Production Process

One step :
Take the pure aluminum material drawing into the aluminium rod wire;

Two step :
Through the extrusion production line, take the aluminum rod wire into extruding and coarse drawing operation, then becoming the requirement specification of Bare aluminium wire;

Three step :
Take up the Bare aluminum wire conductor, and inspection the bare wire coil products;

Four step :
Annealing the bare aluminum wire, and placed neatly, ready to production;

Five step :
Doing the digital dividing and cutting paper process and finished;
Pay-off the wire coil products, ready to paper covering production;

Six step :
Taking into straightening and tension lenvelling operation, ready to paper winding;

Seven step :
Taking into the paper winding operation, and then for inspecion;

Eight step :
Pulling the finished paper-covered wire, and then for take-up the wire coil , ready to packing.

1. Mechanical functions: including elongation, rebound angle, softness and adhesion, paint scraping, tensile strength and other items.
(1) Elongation reflects the plastic degeneration of the material and is used to check the ductility of the enameled wire.
(2) The rebound angle, the softness reflects the elastic deformation of the material, and is used to check the softness of the enameled wire.
¢ÇThe durability of the paint film includes winding and stretching, that is, the promised tensile deformation of the paint film without cracking when the conductor is stretched and deformed.
(4) The adhesion of the paint film includes snap-off and peeling. First, check the adhesion of the paint film to the conductor.
(5) The scratch resistance test of the paint film reflects the strength of the paint film against mechanical scratches.

Paper covered wire by Electrical Aluminium Pole extrusion die by a certain size or drawn wire after annealing, and then in the aluminum conductor wrapped more than two or two insulating paper (including paper, telephone, cable paper, high voltage cable paper, turn insulation paper) of the winding wire, suitable for oil-immersed transformers and other electrical winding with a similar wire. Produced by the extrusion process electrical bare aluminum wire is wrapped production of the cable wire is the best material.

Aromatic polyimide enameled wire has good heat resistance, softening breakdown resistance, radiation resistance, severe cold resistance and chemical resistance. Among them, many test indicators such as unidirectional scratching, breakdown voltage, and thermal softening are far Far better than ordinary enameled wire.

Type: insulated
Delivery time: 7-30 Days
Conductor Material: Copper
Standard: IEC,NEMA,GB,JIS
Diameter: 0.016mm–9.2mm
Brand Name: LP Magnet Wire
Bobbin: 30kg/50kg Wooden Spool

The space factors of magnet wires are compared in the right figure. The space factors of enamelled wires are superior to those of other wires for winding, as are their electrical properties. However, more careful examination must be made of the following properties as compared with other wires.

Wire Enamel Coating is important used for enameled wire or magnet wire, the application is used for transformer winding coils and motor coils forming insulation to prevent short circuits.
