155 Class Enameled Aluminium Wire Export

Rectangular Aluminum Magnet Wire
Rectangular: A> 0.8–8mm, B> 2-22.5mm
Wire Enamel: UEW(QA), PEW(QZ), EIW(QZXY), EI/AIW(QZY) ;
thermal class: 180(Class H), 200(Class C), 220(Class C+), 240(Class HC)

Transformers wound with aluminum or copper coils have similar losses and performance. Losses in the transformer¡¯s coil are a function of the current carrying capacity of the wire or foil used to wind them and the actual current. Therefore, a larger wire is used when winding aluminum coils to make up for the lower current carrying capacity and efficiency of aluminum.

Product Name:enameled aluminum copper wire
Type: flat wire
Round Dimension:28 Gauge
Conductor Material:Aluminum
Application:used for transformers, inductors, motors, generators, dry type transformer, Cast Resin Transformers
Certificate:UL,RoHS
Insulation Materilas: QZ
Thermal Class:155¡æ

Grade: 1000 Series
Width: 20-1900mm
Alloy Or Not: is Alloy
Thickness (mm): 0.2-3.0
Brand Name: LP Industry
Delivery Time: 46-60 days
Processing Service: Bending, Welding, Cutting

Product Name:enameled aluminum wire
Type: round and rectangular aluminum wire
Diension:SWG 31 32 33 34 35 36 38
Conductor Material:aluminum
Application:used for transformers, inductors, motors, generators, dry type transformer, Cast Resin Transformers
Certificate:UL,RoHS
Insulation Materilas:UEW, QZ, QZY, EIW, etc.
Thermal Class:105¡æ, 120¡æ, 140¡æ, 155¡æ, 180¡æ, 200¡æ, 220¡æ, 240¡æ

Width: 20-1900mm
Tolerance: ±1%
Thickness (mm): 0.2-3.0
Standard: ISO9001
Alloy: Is Alloy
Delivery Time: 46-60 days
Brand Name: LP Industry

Specialize used in Refrigeration Compressors.
Fluoride resistant enamelled aluminum round wire
Specification Range : 0.06 to 6.00 mm
Material requirements : resistance to R22 and R134a has a special paint, self-lubricating paint, high purity aluminum;
Production standard : GB/T 6109.20 2008;IEC 60317 – and 97;

Enameled Aluminum Self Bonding Wire In Hot Air Or Alcohol Type: When the alcohol is added to the product, the wound coils are naturally bonded together and directly formed. Hot air self-adhesive is achieved by blowing hot air on the product coil during the coil winding process to achieve the self-adhesive effect. The temperature of the hot air varies according to different paint film, winding speed, wire diameter and other factors.

1)Product Name: Aluminum Enameled Wire
2)Diameter:0.5mm/1.0mm/1.5mm
3)Insulation Properties:Polyester imide enameled wire
4)Use:DIY,transformer,electromagnet
5)Work Temperature:-25¡æ~180¡æ
6)Work Humidity:5%~95%RH

MOQ: 500kg
Size: 0.16-9.2mm
Delivery time: 7-30 Days
Thermal Class: 130C~220C
Brand Name: LP Magnet Wire
Application: transformer,motor,generator,modern instrument

Enameled Magnet Aluminum Wire Strip for winding used in electrical equipment is generally called magnet wire. Simply put, ¡°Magnet wire is used for interchanging electrical energy with magnetic energy¡±.
Magnet wires are broadly divided into enamelled wire (coating insulation), covered conductor wire (fiber/film insulation), other specially formulated wire, and combinations thereof.

Standard: IEC, NEMA,GB,JIS
Size: 0.8mm-7.0mm
Brand Name: LP
Thermal Class: 130-220C
Delivery time: 7days-30days

Product Name:enameled aluminum wire
Type: round and rectangular aluminum wire
Round Diension:0.15-6.5mm
Conductor Material:aluminum
Application:used for transformers, inductors, motors, generators, dry type transformer, Cast Resin Transformers
Certificate:UL,RoHS
Insulation Materilas:UEW, QZ, QZY, EIW, etc.
Thermal Class:105¡æ, 120¡æ, 140¡æ, 155¡æ, 180¡æ, 200¡æ, 220¡æ, 240¡æ

EAL-Enameled Aluminum Wire is a main variety of the winding wire, composed by conductor and insulating layer. After the bare wires are annealed soften, then through many times paint, and bake to the finished product. Enameled wire is a main material for the electrical machine, electrical appliance, household applicance, ect. The different enameled wires have different qualities and characteristics, but all possess mechanical property, chemical property ,electrical property, febricity.

Two method to Distinguish High-quality Aluminium Magnet Wire, one is size, the other is looking the appearance.

180H Rectangular Flat Aluminum Winding Wire For Electric Tools is a wire drawn from a round aluminum rod through a mold of specifications or extruded, and the drawn bare wire is annealed and softened, and then painted and baked for many times. Mainly used in the windings of electrical equipment such as transformers and reactors.

1) Acetal enameled wire (QQ) – E-class 120¡æ
2) Polyester enameled wire (QZ/130) – B grade 130¡æ
3) Modified polyester enameled wire (QZ/155) – F grade 155¡æ
4) Modified polyester imine enameled wire (QZY/180)-H class 180¡æ
5) Amide-imide enameled wire (QZY, QZY/200)-Class C 200¡æ
6) Polyimide enameled wire (QY/220) -C level 220¡æ

High Quality Thin Insulated Solderable Enameled Aluminum Wire is used for Ttansformers, motors, and generators are all machines based on coils, which are devices that use large coils to generate magnetic fields and currents.

The electric motor winding definition is, windings in electric motors are wires that are placed within coils, generally enclosed around a coated flexible iron magnetic core to shape magnetic poles while strengthened with the current. Electric machines are available in two fundamental magnet field pole configurations namely salient pole as well as a non-salient pole.

Aluminum Magnet Wire can be divided into round aluminum wire and flat aluminum wire, also includes self-bonding aluminum wire and soldering aluminum wire. and aluminum magnet wire is widely usedfor transformers, inductors, motors, generators, dry type transformer, Cast Resin Transformers

Single-layer Enameled Aluminum Flat Wire Insulated Aluminium Winding Wires are suitable for all “H”, “F” and “B” category applications, such as dry-type transformers, stator winding fractional HP motors, DC magnetic field and armature windings. Wires coated with polyester have good chemical resistance and are compatible with all common impregnating varnishes, including high-temperature modified phenolic polyester and other varnishes that do not contain reactive solvents.

Aluminum is not only cheaper than copper, but also as an excellent conductor, it has better flexibility than copper, its density is only 1/3 of copper, and the same weight of aluminum conducts electricity twice as much as copper; therefore, aluminum Wire requires a larger wire gauge than copper wire to conduct the same current.
Compared with copper, another advantage of enameled round aluminum wire is that the NEMA standard recognizes aluminum wire as a higher thermal enameled wire. For example, replacing copper wires with aluminum wires, using high-temperature polyester TeresterR@ C966, and composite polyamide-imide topcoat, the thermal level can be increased from 200 to .220. The reason is that during the aging experiment of the enameled copper wire, the catalysis of copper ions promotes the aging of the paint film.

China Supplier Wholesale Magnet Cable Coated Enameled Aluminum Wire Price

Brand Name: LP
Conductor Type: Solid
Diameter: a:1-10,b:3-16
Standard: IEC,NEMA,GB,JIS
Bobbin: 30/50kg wooden spool
Temperature class: 180,200,220
Conductor Material: Aluminum

Enameled rectangular wire is drawn from electrical round aluminum rod with certain specification mould. With mold type or blanket type, it is painted with compatible insulating coatings. After the product is baked, conductor and insulated coating make a whole. The product is widely applied in transformers, electric powers, electromotors, reactors and other similar electrical instruments.

Thermal Class: 130-220C
Delivery time: 7-30 Days
Brand Name: LP Magnet Wire
Model Number: Aluminum Flat Wire
Bobbin: 30kg/50kgWooden Spool
Certification: SGS,UL,ISO9001,ISO4001

Model number: Q(ZY/X)-1/180, Q(ZY/X)-2/180 (2EIWN, 1EIWN)
Specification Grid: 0.100-3.000
Heat resistance level: 180 level
Implementation standard: GB/T 6109.12
Performance characteristics: can be used at a working temperature of 180. The product has excellent heat resistance, high thermal shock performance, small surface friction coefficient, and excellent mechanical properties.
Application area:Widely used in motors, electrical appliances, instruments, explosion-proof motors and marine motors with high heat-resistance levels, as well as horizontal windings for color tube deflection. Especially suitable for high-speed winding machine wire coils.

PT-25 PT-30 2.40mm Aluminum Enameled Transformer Winding Wire means that the one spool of winding wire is about 25kg or 30kg. Conical magnet wire delivery spool is made of plastic materials, used for below 5kg. The tapered design not only maximizes the winding volume of the spool, but also ensures the smooth winding process. But the 25kg and 30kg aluminum enameled transformer winding wire normally uses the wooden rool. All product data may have slight deviations, and the tolerance values ??are within the range of industry standards. The packaging and transportation process of the tapered magnet wire conveyor spool has the characteristics of high strength, strong impact resistance, and good balance.

Enameled aluminum wire
Diameter: 0.8-8mm
Temperature Class : 180 , 200 , 220
Standard : IEC 60317-0-2 ,IEC 60317-29 , MW36-A
UL NO : E345303
Bobbin :150kg wooden spool , plastic spool .
Application : Transformer , generator , refrigeration system

Product Name:enameled aluminum round wire
Type: flat wire
Round Dimension:A> 0.8–8mm, B> 2-22.5mm
Conductor Material:Aluminum
Application:used for transformers, inductors, motors, generators, dry type transformer, Cast Resin Transformers
Certificate:UL,RoHS
Insulation Materilas:UEW, QZ, QZY, EIW, etc.
Thermal Class:105¡æ, 120¡æ, 140¡æ, 155¡æ, 180¡æ, 200¡æ, 220¡æ, 240¡æ
