0.17mm CCA coil magnet wire enameled copper clad aluminum wire

Copper-clad aluminum wire is made of a solid aluminum core covered with a copper skin in order to improve its performance in the field. Copper clad aluminum wire is very different from solid EC grade aluminum wire. For one, CCA belongs to a species of metals known as ¡°Bimetallics,¡±
Conductor materials: copper and aluminum

Precautions for storage should be well packaged, should not be placed in a high-humidity warehouse, should not be exposed to direct sunlight, and should not be placed near acids, alkalis and organic solvents.

What is the difference between magnet wire and enameled wire? Enameled wire is a type of magnet wire. but most people called the magnet wire in winding wire or enameled wire. Mostly used for Inductors, transformers, reactors, dry-type transformers, cast resin transformers

Enamelled Covered Aluminium Wire Production Process

One step :
Take the pure aluminum material drawing into the aluminium rod wire;

Two step :
Through the extrusion production line, take the aluminum rod wire into extruding and coarse drawing operation, then becoming the requirement specification of Bare aluminium wire;

Three step :
Take up the Bare aluminum wire conductor, and inspection the bare wire coil products;

Four step :
Trough the enameled covered production line, taking cleaning¡¢annealing and drying operation , and ready to enameled covered step;

Five step :
Taking into enameling operation, and then for cooling and lubricanting;

Six step :
Through the on-line monitoring equipment, inspecion the quality of enameled wire, and take up the fulfillment products.

Seven step :
Packing the enameled wire products, and placed neatly in warehouse.

Polyimide Kapton Covered Enameled Aluminum Wire Strip is a multi-layer polyimide & fluoropolymer dispersion-coated film. The fluoropolymer coating functions as a heat-fusible layer for bonding to magnet wire conductors. It has superior scrape abrasion resistance and exhibits lower frictional properties than wire insulated with other commonly used polyimide materials. Polyimide film aluminum wire is ideal for demanding magnet wire applications and for difficult-to-wind motors.

Enameled wire is a main type of magnet winding wire. It is composed of a conductor and an insulating layer. After the bare wire is softened by annealing, it is painted and baked many times. However, it is not easy to produce products that not only meet the requirements of the standard, but also meet the requirements of customers. It is affected by the quality of raw materials, process parameters, production equipment, environment and other factors. Therefore, the quality characteristics of various enameled wires are different, but they all have Mechanical properties, chemical properties, electrical properties, and thermal properties

Glass-fiber covered aluminum magnet wire used to have weak coating strength (abrasion resistance, shock resistance, and flexibility). However, that disadvantage has been significantly improved recently by refining material selection and manufacturing methods. The demand for glass-fiber covered aluminum magnet wire is increasing as the wires have excellent uniformity and electrical properties under high temperatures and humidity.

Main Applications:
All kinds of household electric motors, vacuum cleaner motor, electric motor
All kinds of transformers, inductors, rectifiers
All kinds of fan motor
All kinds of high frequency electric appliance

Good Quality Paper Covered Flat Aluminum Enameled Copper Wire is made of bare copper wire or bare aluminum wire, or paper-covered wire as the core, wrapped with paper for insulation. According to customer and national standards, the conductor is wrapped with telephone paper, electromagnetic paper, and high-density inter-turn insulation paper. As conductor insulation, it is an ideal material for civilian-made oil-immersed transformers; especially semi-hard insulated copper wires, which can significantly improve the winding resistance. The mechanical properties and short-circuit resistance can be widely used in the winding of large and medium-sized transformers.

The enameled wire has always been a very important industry in the national economy, and with the continuous change and development of the market, the enameled wire industry is constantly adjusting, from the current perspective, the future of the entire enamel wire industry will move towards the future.

The environmental painted wires of the lacquer formula contains the shortening project development time, saving project funding, and significantly improving the quality of the project.

High Temperature Aluminum Magnet Wire (Anodized aluminium wire) belongs to the special electromagnetic wire and the insulation layer is the aluminum oxide . Because of no thermal aging phenomenon, it can be used as insulation level of class 220.
The insulation layer of such product is thin, high temperature resistance and insulation performance stability,which is the best choice for low voltage winding wires with producing high temperature, poor environment, heat dissipation difficulty and so on.
It can widely be used in electromagnetic industries at home and abroad.

Enameled wire is a main type of winding wire. It consists of a conductor and an insulating layer. After the bare wire is softened by annealing, it is painted and baked many times. However, it is not easy to produce products that not only meet the requirements of the standard, but also meet the requirements of customers. It is affected by the quality of raw materials, process parameters, production equipment, environment and other factors. Therefore, the quality characteristics of various enameled wires are different, but they all have Mechanical properties, chemical properties, electrical properties, and thermal properties are four major properties.

Magnet wire is an insulated wire used to make coils or windings in electrical products. Also called winding wire. Magnet wires must meet the requirements of a variety of uses and manufacturing processes. The former includes its shape, size, ability to work at high temperatures for short and long periods of time, as well as withstanding strong vibration and centrifugal force at high speeds in some occasions, resistance to corona and breakdown under high voltage, and resistance to chemicals in special atmospheres Corrosion, etc.; the latter includes the requirements of stretching, bending and abrasion during winding and embedding, as well as swelling and erosion during dipping and drying.

The enamel wire is a wire having an insulating layer, which is a transformation of electromagnetic energy in a winding form, also known as a winding wire.

These Paper wrapped insulated aluminium wires enamelled and Strips are made from very high quality raw material which ensures hassle free work performance at its user end. These Paper Covered Aluminum Wires and Strips are technologically advanced and confirm to industrial quality norms of international standard. These Paper Covered Aluminum Wires and Strips are widely finds its applications in various industrial sectors.

Advantages of enameled CCA wire:
As envelope alternatives of pure enameled copper wire, it has good performance of high frequency transmission, originally it was applied in various types of high-frequency electromagnetic induction coil; now in order to save more production cost, ECCA wire has been widely used in various types of electronic coils, transformers, inductors, rectifiers, and all kinds of large and small motors, and has excellent soldering performance. Its density is low, the weight of the unit product can at least save 40% of the copper wire, it can save a lot of cost of production material.

Enameled aluminum wire ,High resistance to heat shock, high temperature and good performace at softening breakdown, suitable for high-speed automated routing, able to be direct weld, with no pinhole, resistive to high frequency, wearing, refrigerants and electronics corona, high breakdown voltage

The wrapped wire is made of natural silk, polyester fiber, glass fiber, insulating paper or synthetic resin film, etc., tightly wrapped on the conductive wire core to form an insulating layer. There are also insulating layers wrapped around the enameled wire. In addition to thin-film insulation, others such as glass filaments need to be dipped in adhesive insulating varnish to improve their electrical, mechanical and moisture-proof properties. In fact, they are combined insulation.

The paint is a process of painting the paint of the enameled wire to form a uniform lacquer layer of a thickness on the metal conductor. This is related to several physical phenomena and painting methods of liquid.

Enameled Aluminum Wire Compared To Enameled Copper Wire have some advantages
Aluminum /Copper Wire/foils
Dimension:0.2–10.0mm,
Rectangular: A> 0.8–8mm, B> 2-22.5mm
Square: 0.4*0.4mm–8*8mm
Foils:Thickness：0.2–2.5mm, width:60–1250mm

The coating is a process of forming a uniform coating layer of a coating wire to form a uniform coating layer on a metal conductor. This is related to some physical phenomena and painting methods of liquid.

Double Glass-fiber Covered Rectangular Aluminum Wire is a kind of winding wire made by electrician round aluminum rod drawn or extruded into a rectangular conductor by a certain specification die, and then a double glass fiber insulation layer is wrapped on the rectangular conductor.

Enameled round aluminum wire is made of oxygen free rod or electrical aluminum rod by a certain size of the die drawing or extrusion of the wire, the insulation paint through many times of the winding wire. Mainly used in winding of transformers, motors, generators, and various electrical devices.

Copper-clad aluminum wire refers to a wire with aluminum core wire as the main body and a certain proportion of copper layer plated on the outside. It can be used as a conductor for coaxial cables and wire and cable conductors in electrical equipment. The aluminum wire has a small specific gravity, but its welding performance is not good. Therefore, the copper-clad aluminum wire is wrapped with a copper layer on the aluminum wire. This copper-clad aluminum wire can not only take advantage of the small aluminum specific gravity, but also improve the welding performance.

Type of magnetic wire is divided into enameled wire, wrapping wire, insulated wire, combined wires and others,Mainly used in motors, electrical appliances, instruments, transformers, etc., to generate electromagnetic effects by winding coils, and use the principle of electromagnetic induction to achieve the purpose of converting electrical energy to magnetic energy

The temperature resistance of composite enameled wire can reach above 520 degrees.
Composite enameled wire is an ideal wrapping wire for large-scale low-voltage and high-current electrical appliances such as power oil-immersed, dry-type, special transformers, electric welding machines, reactor rectifiers, electromagnetic separators, etc., with excellent electrical performance and stability.

Product details :
Place of origin : Henan ,China(Mainland);
Brand name : Signi;
Type : Insulated;
Conductor material : Aluminum;
Conductor type : Solid;
Insulation material : Enameled;
Diameter : 0.025-4.5mm;
Color : Natural;
Thickness : Grade 1/2/3;
Thermal Class : 130-220c;
Application : Motor,transformer,welding machine and generator;

The electrical insulation system for wires used in generators, electric motors, transformers, and other wire-wound electrical components is divided into different classes by temperature and temperature rise. The electrical insulation system is sometimes referred to as insulation class or thermal classification. The different classes are defined by NEMA, Underwriters Laboratories (UL), and IEC standards.

Water quality affects the production of lacquer wires?

The production water production water in the lacquered wire has a variety of uses, and like, the requirements for water quality are also different. Depending on the purpose of use, the water quality can be divided into: annealing furnace water seal water, equipment cooling water, lubricant manufacturing water, etc.
